1220*2440 OSB Board /Oriented Strand Board Production Manufacturing Machine for Wood Based Panel Industry
During the molding of the osb, the upper and lower surfaces of the oriented strand board arrange the mixed glue particleboard in the direction of its fiber, while the core layer particleboard is arranged horizontally to form a three-layer structural board embryo, and then the oriented strand board is made by hot press.
The shape of this particleboard requires a relatively large length and width, and the thickness is slightly thicker than that of ordinary particleboard. Directional paving/forming methods include mechanical orientation and electrostatic orientation. The former is suitable for large shavings oriented paving, while the latter is suitable for small shavings oriented paving. The directional paving of particleboard makes it have the characteristics of high strength in a certain direction, and it is often used instead of plywood as structural materials.
China Manufacturing OSB Board (Oriented Strand Board) Production Line with Yearly 100000cbm
>>>>Oriented Strand Board(OSB)
During the molding of the osb, the upper and lower surfaces of the oriented strand board arrange the mixed glue particleboard in the direction of its fiber, while the core layer particleboard is arranged horizontally to form a three-layer structural board embryo, and then the oriented strand board is made by hot press.
The shape of this particleboard requires a relatively large length and width, and the thickness is slightly thicker than that of ordinary particleboard. Directional paving/forming methods include mechanical orientation and electrostatic orientation. The former is suitable for large shavings oriented paving, while the latter is suitable for small shavings oriented paving. The directional paving of particleboard makes it have the characteristics of high strength in a certain direction, and it is often used instead of plywood as structural materials.
>>>> Main OSB Production Machine
Drum chipper for crushing wood and barks and trunks into the certaine size chips;
Vibrating screen for screening big wood strands, suitable strands, and chips;
Drying machine for drying the wet wood strands;
Gluing machine for make glue on wood strands and evenly distributed;
Forming line for uniform distribution of the flakes both lengthwise and crosswise as well as the layer formation of top and middle layer flakes over the cross section of the panel;
Continuous press machine for pre-press particleboard, and make it in a certaine initial strength;
Multi-layers Hot press machine for pressing osb board by high heating temperature and pressure;
Sanding machine for sanding particleboard surface, and make its surface smooth and thickness accurate;
Cutting machine for cutting the trimmed chipboard into the required sizes and specifications, usually with both cross-cutting and longitudinal cutting methods.
>>>> Specification of the Full OSB Line
Name
Sieving Machine
Sieving capacity
150-200m3/h
Sieve mesh
2
Sieving area
10m2
Name
Drum dryer
Original moisture
less than 80%
End moisture
2%
Heating medium
fume air
Name
Continuous pre press
Belt width
1500mm
Transmission speed
10-30m/min
Working height
1250mm
Layers
22
Pressure
1200ton
Hot plate size
2650*1680*120mm
Oil cylinder
Dia 400mm*4pcs
Hydraulic system pressure
25Mpa
Heating medium
less than 180℃
Closing time
10s
Note: Specification can be customized according to different requires.
>>>>Company Profile
Our factory mainly produce the full line of osb board making machine, particle board making machine, and mdf board making machine. With many years production experience, and advanced production equipment and technology, we promise that we can make and offer suitable and good machine for you.
Therefore, if you plan or interested to produce particle board or oriented strand board or medium density board, welcome contact us. According to your production capacity and factory conditions, we can design and offer the good machine.
The whole production line mainly includes wood chipper/flaker, drum dryer, gluing system, forming machine, pre press machine, cutting machine, hot press, sanding machine, and these machine includes kinds of related parts too.
Our factory insist to use good material and parts, and improve our machine in every period, to make our machine better and better.
>>>>After Sale Service
<1> Machine Installation: We can send engineers go to install machine, degue, and teach your workers
<2> Warranty: 2 years
<3> Factory layout: After machine production start, we can make factory layout for you
<4> If meet problem when operation machine Contact us at the first time, our engineers will help check and solve quickly.
Welcome contact us for more information if you are interested.
