MH-HP
MINGHUNG

This hot press is designed around the core concept of "fast close, fast press, fast decompress, fast open":
1. Fast Closing: A high-flow hydraulic system combined with auxiliary fill valves allows the hot platens to close within seconds.
2. Pressurizing & Pressure Holding: The main cylinders apply set pressure, rapidly curing the adhesive in 1.5-6mm thin boards under high temperature.
3. Fast Decompression & Opening: Quick exhaust valves rapidly release pressure while the hydraulic system lifts the platens quickly, reducing overheating of thin boards.
4. Precise Thickness Control: High-precision mechanical or servo thickness stops ensure board thickness within ±0.1mm.
The heating system continuously provides uniform heat to each platen. Combined with a short pressure-holding period, this achieves highly efficient curing of thin boards.
Main Components
1. High-Speed Hydraulic Station: High-flow pump set (dual or triple pumps) supporting fast closing and opening.
2. Fast Closing Mechanism: Fill valves and auxiliary cylinders reduce closing time.
3. Multi-Layer Hot Platens (customizable layers): Uniform heat distribution, high surface flatness — specially designed for thin boards.
4. Thickness Stop Device: Mechanical or servo-controlled stops for precise board thickness.
5. Heating System: Optional thermal oil / electric / steam heating with even temperature distribution.
6. PLC High-Speed Control System: Supports multi-stage pressure/time curves and fast recipe switching.
7. Synchronized Lifting System: Ensures parallel movement of all platens, preventing uneven pressure and distortion.
8. Fast Decompression Valve Set: Enables instantaneous pressure release to prevent surface scorching of thin boards.
Key Advantages
Advantage | Description |
High-Speed Production | Single cycle time reduced to 50%–70% of traditional machines, ideal for continuous mass production of 1.5-6mm thin boards. |
High Thickness Precision | Thickness stops or servo position control ensure thickness tolerance ≤ ±0.1mm. |
Excellent Flatness | Fast closing and uniform heating prevent warping; finished boards have superior flatness. |
Uniform Temperature Control | Platen temperature difference ≤ ±2°C, avoiding local overheating or under-curing. |
Flexible Operation | Fast switching between recipes for different board thicknesses, suitable for varied production. |
Energy Optimized | Shorter pressure-holding cycles reduce heat loss and lower energy consumption per unit product. |
Compact Structure | Optimized frame height for thin board operation, easy loading/unloading. |
Parameter | Typical Value (Customizable) |
Applicable Thickness Range | 1.5 – 6 mm |
Number of Layers | 10–30 layers (based on output requirement) |
Total Pressure | 200–1200 tons |
Hot Platen Size | Customizable (e.g., 2500×1250mm, 2000×1000mm) |
Working Temperature | Ambient–200°C |
Temperature Control Accuracy | ±2°C |
Thickness Tolerance | ≤±0.1mm |
Hydraulic Station Power | 18.5–37kW |
Heating Method | Thermal oil / Electric / Steam |
Control System | PLC + Touch Screen (multi recipe storage) |
Frequently Asked Questions (FAQ)
1. Can this hot press produce boards thinner than 1.5mm?
A: 1.5mm is the optimal economic thickness. For thinner boards (e.g., 0.8-1.2mm), we can customize thickness stops and finer temperature control.
2. Thin boards tend to warp during hot pressing. How do you prevent this?
A: Our design uses fast closing, fast opening, uniform heating, high-flatness platens, and a synchronized system to minimize temperature differences and internal stress, effectively preventing warping.
3. Can the machine produce different thickness boards in the same batch?
A: It is recommended to run the same thickness per batch. When changing thickness, simply switch the recipe on the PLC — no mechanical adjustment needed.
4. What types of thin boards is this machine suitable for?
A: Suitable for poplar, eucalyptus, birch thin plywood, as well as decorative panels, aircraft panel base layers, and backing boards.
5. Does it support automatic loading/unloading?
A: Yes. We can provide automatic board loaders, unloaders, and conveyors for high-speed inline thin board production.
