spindleless veneer peeling machine
spindleless veneer peeling machine is one of the important equipments for plywood production.
MINGHUNG MH-VPM1500G type spindleless veneer peeling machine, suitable for veneer peeling machine for logs and wood cores with a diameter of Φ500mm or less, the final wood core is less than 30mm in diameter. It can greatly improve the utilization rate of wood and improve the production efficiency of veneer. The advantage of this machine is that it adopts CNC servo motor, PLC controls the feed, and the high-precision lead screw ensures the feeding accuracy; it can ensure the uniform thickness of the veneer cut out. Secondly, the single and double rollers of the main machine all use dual power motors, which have stable operation and noise. Small and not easy to damage. The overall structure of this machine is reasonable, the operation is simple, the maintenance is convenient, and it can provide a strong veneer production capacity.
The main specifications and technical parameters of the MH-VPM1500G type: 1. Machine parameters ① hard tooth surface reducer, ② main engine speed 65 rpm ③ Roller diameter Φ120 mm ④ Transmission ratio 1:1 ⑤ Worm gear box speed ratio 1:10 ⑥ Feed screw pitch 26mm2. Power: ① Feed servo motor 11KW) 1 set ② Main drive motor 7.5 (KW) 2 sets 3. The output speed is 50-80 m/min. 4. The maximum diameter of the rotary log is Φ500mm, and the final core diameter is less than or equal to 30mm. Length 1500*1300*12.7mm7.spindleless veneer peeling machine Overall dimensions of the machine (length*width*height) 4500*2200*1700 (mm) 8. The net weight of the machine is 7500kg
The speed of spingleless veneer peeling machine can be up to 120m/min. The overall structure of the machine has passed the mechanical test, and the weight reaches 7500kg. It is a heavy-duty Veneer lathe, and the weighted fuselage mechanism makes the machine more stable during operation.
high speed veneer roatry cutting heavey duty veneer lathe
The high-speed rotary cutting of veneer not only ensures the production efficiency of the veneer, but also ensures the uniform thickness of the veneer rotary cutting.
The spindleless veneer peeling machine uses a servo motor for feeding, and the servo motor is controlled by a servo inverter to control the operation of the machine with high precision, and the thickness of the veneer is uniform.
The guillotine knife system adopts a servo motor, and the servo motor is controlled by a servo inverter to control the guillotine knife with high precision.
Delivery details:
