Four Rollers Plywood Core Coating Glue Spreader
You are here: Home » Plywood Machine Series » Glue Spreader » Four Rollers Plywood Core Coating Glue Spreader

PRODUCT CATEGORY

Four Rollers Plywood Core Coating Glue Spreader

Availability:
Quantity:
Four Rollers Plywood Core Coating Glue Spreader
Four Rollers Plywood Core Coating Glue Spreader
glue spreader's function is coating glue on the surface of wood veneer, then lay them out into plywood size.
The four-roll gluing machine is to add an extruding roller beside the upper and lower gluing rollers to control the gluing amount on the upper and lower surfaces of the single board respectively. The linear speed of the extrusion roller is 15%~20% lower than that of the coating roller, which plays the role of scraping, and the gap between the extrusion roller and the coating roller is adjustable to ensure that the thickness of the upper and lower rubber layer is uniform. The upper and lower rubber rollers provide glue at the same time, non-interference, glue is not easy to produce beating, is a widely used glue equipment.

There are two kinds of arrangement for the extrusion roller of the four - roll applicator. 1) The upper and lower extruded rubber rollers are arranged on both sides of the rubber rollers respectively, and the rubber pump provides glue through the rubber hose respectively; 2) The upper and lower extruding rollers are located at the feeding side of the rubber applicator. The upper rubber applicator is supplied by the rubber pump, and the lower rubber applicator is supplied by the lower rubber groove. Due to the different arrangement of the roller and the way to supply glue, its role is also different. The former coating uniform, can save glue material; The latter applies when productivity is relatively high.

folding


>>> SPECIFICATION
name glue spreader machine
model MH-GSM8
type double sides at the same time
diameter of rubber roller 310mm
length of roller 2700mm
power 5.5kw
weight 2800kg
size 3250*1250*1700mm

>>> DELIVERY INFO
1. Payment terms
T/T. 30% as deposit, 70% before delivery.

2. Production date
one month

3. Warranty
2 years


>>> ADVANTAGES
Four Rollers Plywood Core Coating Glue Spreader
Four Rollers Plywood Core Coating Glue Spreader
Four Rollers Plywood Core Coating Glue Spreader
Four Rollers Plywood Core Coating Glue Spreader
Four Rollers Plywood Core Coating Glue Spreader
Four Rollers Plywood Core Coating Glue Spreader


<1> Glue spreader's structure is simple, easy operate.
<2> Transmission by gear & chain, fast speed, high efficiency.
<3> Using good and big diameter roller, good quality



>>> FACTORY
Four Rollers Plywood Core Coating Glue Spreader
We-Shandong MINGHUNG Wood Machinery is one of the leaders of plywood machine in China, supplies a complete range of machinery, systems and technology for the production of plywood and veneer including wood debarker, veneer peeling machine, vacuum veneer stacker, knife grinder, veneer dryer machine, glue spreader, cold press, hot press machine, plywood saw machine, sanding machine.

Highly qualified personnel and competent management take all the advantages of production and continue developing day by day, the basis of our business is focus on our clients' needs, such position allows us to build long-term partnership with our clients in China and abroad.

We also works closely with a global network of manufacturing partners in order of provide the reliable, good quality and service to our customers.



>>> CLIENTS
we sincere treat every our client, insist offer good and suitable machine to you.
the moment when you choose us, we have been your reliable partner, you not just buy machine from us, we will offer the service anytime when you need about machine.
Four Rollers Plywood Core Coating Glue Spreader


>>> DELIVERY
Four Rollers Plywood Core Coating Glue Spreader
Before loading, our engineer will test machine many times, for make sure machine in good conditions.
When loading, we will share your machine loading pictures to you.
After ship leave, we will offer ship information and documents to you.
